As-Built Drawing Services

As-built drawing preparation depicting the final condition of a building as actually constructed, a required document for SLF applications.

Please contact usEst.: 2 - 4 weeks

About Service As-Built Drawing

An as-built drawing is a technical drawing showing the actual condition of a building after construction is complete, including all changes made from the original design. This document is a mandatory requirement when applying for a Certificate of Function Worthiness (SLF), as well as for future building maintenance purposes.

Our team assists with on-site re-measurement and adjusting architectural, structural, and mechanical-electrical drawings to match the actual condition of the building, carried out by experienced professionals.

What's Included in This Service

Initial consultation & original design drawing review

On-site building re-measurement

Architectural, structural, and MEP drawing adjustments

Field condition compliance verification

Redrafting to technical standards

Revisions until approved

Free initial consultation

Process Steps

Initial consultation & requirement identification

On-site building re-measurement

Original design drawing collection for comparison

Adjustment and redrafting

Actual condition compliance verification

Revision (if required)

Final as-built drawing document handover

Service Summary

ServiceAs-Built Drawing

Estimated CostPlease contact us

Duration2 - 4 weeks

Consult Now

Free, no commitment

Team Certifications

KTPAATPALPJP

FAQ about As-Built Drawing

An as-built drawing is a technical drawing of a building final condition after construction, generally required as part of an SLF application.

Generally 2-4 weeks, depending on the building size and complexity.

The original design drawing is the pre-construction plan, while an as-built drawing depicts the actual condition of the building after all changes made during construction.
